Pax-i3D Smart(PHT-30LFO) Installation Manual
65
4 Installing the Equipment: Floor Standing (Optional)
Leveling right and left
1. Place the spirit level, as shown in the gure..
2.
Adjust the base until the bubble on the spirit
level centers in the middle, by turning left and
right screws clockwise or vice versa.
Leveling the front and back
3.
Place the spirit level on the vertical frame, as
shown in the following gure.
4.
Adjust the screws until bubble of spirit level
centers (level), by turning the front and/or
back screws clockwise or vice versa.
