Guidance and manufacturer’s declaration - electromagnetic immunity
The model PaX-i3D Smart(PHT-30LFO) is intended for use in the electromagnetic environment
specified below. The customer or the user of the model PaX-i3D Smart(PHT-30LFO) should
assure that it is used in such an environment.
Emissions test Compliance Compliance level
Electromagnetic environment
-guidance
Electrostatic
discharge (ESD)
IEC 61000-4-2
±6 kV Contact ±8
kV air
±6 kV Contact ±8
kV air
Floors should be wood,
concrete or ceramic tile. If floors
are covered with synthetic
material, the relative humidity
should be at least 30 %.
Electrical fast
transient/burst
IEC 61000-4-4
±2 kV for power
supply lines ±1 kV
for input/output
lines
±2 kV for power
supply lines ±1 kV
for input/output
lines
Mains power quality should be
that of a typical commercial or
hospital environment.
Surge
IEC 61000-4-5
±1 kV line(s) to
line(s) ±2 kV line(s)
to earth
±1 kV line(s) to
line(s) ±2 kV line(s)
to earth
Mains power quality should be
that of a typical commercial or
hospital environment.
Voltage
dips, short
interruptions and
voltage variations
on power supply
input lines
IEC 61000-4-11
< 5 % U
T (> 95
% dip in U
T) for
0.5cycle 40 % U
T
(60 % dip in U
T )
for 5 cycle, 6 cycle
70 % U
T (30 % dip
in U
T) for 25 cycle,
30 cycle <5 % U
T
(< 95 % dip in U
T )
for 5 s
< 5 % U
T (> 95
% dip in U
T) for
0.5cycle 40 % U
T
(60 % dip in U
T )
for 5 cycle, 6 cycle
70 % U
T (30 % dip
in U
T) for 25 cycle,
30 cycle <5 % U
T
(< 95 % dip in U
T )
for 5 s
Mains power quality should be
that of a typical commercial
or hospital environment. If the
user of the model PaX-i3D
Smart(PHT-30LFO) image
intensifier requires continued
operation during power mains
interruptions, it is recommended
that the model PaX-i3D
Smart(PHT-30LFO) be powered
from an uninterruptible power
supply.
Power frequency
(50/60 Hz)
magnetic field
IEC 61000-4-8
3 A/m 3 A/m Power frequency magnetic fields
should be at levels characteristic
of a typical location in a
typical commercial or hospital
environment.
NOTE) U
T is the a.c. mains voltage prior to application of the test level.
