Vatech PaX-i3D Smart User Manual

132 I
PaX-i3D Smart
13.1 Recommended X-ray Exposure Table
❚
A. PANO
Standard / TMJ / Sinus
Gender / Figure Hard (kVp / mA) Normal (kVp / mA) Soft (kVp / mA)
Man
75 / 12 74 / 12 73 / 12
Woman
74 / 12 73 / 12 72 / 12
Child
68 / 10 67 / 10 66 / 10
* Tube voltage and current variation range in the PANORAMIC mode (recommended): 50 ~ 80
kVp, 4 ~ 14 mA
❚
B. CEPH (Scan)
Lateral / Full Lateral
Figure
Gender
Hard (kVp / mA) Normal (kVp / mA) Soft (kVp / mA)
Man
87/10 85/10 83/10
Woman
85/10 83/10 81/10
Child
82/10 80/10 78/10
PA / SMV / Waters View
Figure
Gender
Hard (kVp / mA) Normal (kVp / mA) Soft (kVp / mA)
Man
90/10 88/10 86/10
Woman
88/10 86/10 84/10
Child
85/10 83/10 80/10
13. Appendices
