7. Acquiring CEPH images
84
I
PaX-i3D Smart
6. The values of tube voltage and current are configured automatically according to
the patient's gender and x-ray intensity. Click the arrow button to zoom in. The
dose is adjustable by ±1 kVp and ±0.1 mA respectively.
7. Once the configuration has been completed, click the CONFIRM button.
When you click CONFIRM button:
● The READY button will begin blinking to show that it has been activated.
● The Scan Time and DAP values will be shown on the Imaging Status Window.
8. Guide the patient to the equipment.
To Next Page
