Engine (continued)
Removing the PTO Electric Clutch
Figure 15
G437639
Bolt
Washer
PTO electric clutch
1. Park the machine on a level surface, lower any attachments to the ground,
engage the parking brake, and remove the key from the ignition.
2. Switch the main circuit breaker to the O
FF position, to de-energize the electrical
system.
3. Remove the grill; refer to Removing and Installing the Grill, page 7–14.
4. Remove the PTO drive belt.
5. Locate the PTO electric clutch
on the engine crankshaft and disconnect the
clutch electrical connector from the main wiring harness.
6. Remove the bolt
and washer securing the clutch to the crankshaft.
7. Remove the clutch from the crankshaft.
Engine: Engine Service and Repairs Page 4–24 4520Z
09.40001Rev 00
