PRODUCT SPECIFICATIONS
SYSTEM SPECIFICATIONS
Table 13. AVL System Specification
GENERAL SPECIFICATIONS
Classification: Electrical Class II, Applied Part BF
Line voltage:
Range: 100–240 VAC, 50 and 60 Hz. Connect to a medical‑grade power supply
(If the provided power cord has a third prong, it is used as a functional ground).
DC power supply: 12 V DC, 2.5 A max
Fuse: Internal 2.5 A Hold / 5 A Trip, 15 V max
Ingress protection
against water:
Video monitor IP54
Video baton IPX8
Expected product life:
Video baton 1‑2 2 years or 1000 cycles
Video baton 3‑4 2 years or 1000 cycles
Video Baton 2.0 Large (3‑4) 2 years or 2000 cycles
Single‑use Stat 1 use or 3‑year shelf life
OPERATING AND STORAGE SPECIFICATIONS
Operating Specifications
Temperature: 10 to 40°C (50 to 104°F)
Relative humidity: 0 to 95%
Atmospheric pressure: 700–1060 hPa
Shipping and Storage Conditions
Temperature: ‑20 to 45°C (‑4 to 113°F)
Relative humidity: 0 to 95%
Atmospheric pressure: 440–1060 hPa
