CABINET ANCHOR DIMENSIONAL & GENERAL DATA
LIEBERT DRYCOOLER
1-4 FAN QUIET-LINE MODELS
*D**040 3110 (5285) 2592 (4404) 2.4 (9.1) 375 (170)
*D**057 2990 (5081) 2492 (4234) 3.7 (14) 395 (179)
*D**060 2840 (4826 2367 (4021) 4.9 (18.5) 415 (188)
*D**080 6220 (10569) 5183 (8808) 4.8 (18.2) 500 (227)
*D**111 5980 (10161) 4983 (8468) 6.9 (26.1) 540 (245)
*D**121 5680 (9651) 4733 (8043) 9 (34.1) 580 (263)
*D**158 8970 (15242) 7475 (12702) 10 (37.9) 735 (333)
*D**173 8520 (14477) 7100 (12064) 13.1 (49.6) 795 (361)
*D**178 7440 (12462) 6200 (10535) 19.4 (73.4) 855 (388)
*D**205 11680 (19847) 9733 (16539) 13.1 (49.6) 940 (426)
*D**248 11360 (19303) 9467 (16086) 17.4 (65.9) 1020 (463)
N/A
80 (2032)
Quiet-Line Model No. of fans
A
in. (mm)
B
in. (mm)
C
in. (mm)
1
2
3
4
51-1/2 (1308)
91-1/2 (2324)
131-1/2 (3340)
171-1/2 (4356)
44 (1118)
CFM (I/s)
60Hz (See note 1)
CFM (I/s)
50Hz (See note 1)
Internal Volume
Gal. (Liters)
Dry Wt.
Lbs. (kg)
D
in. (mm)
82 (2083)164 (4166)
84 (2134)
124 (3150)
42 (1067
82 (2083)
122 (3099)
43 9/16"
1107mm
A
64 3/8"
1635mm
Typ.
Disconnect
Switch
Eyebolts for lifting Drycooler
provided on 4 fan models only
Inlet Connection
(upper header)
Outlet Connection
(lower header)
4 3/4"
121mm
43 3/16"
1097mm
B
37 7/8"
962mm
43 1/8"
1095mm
TOP OF
FAN GUARD
Unit Anchor Plan
B
C
D
37 11/16"
957mm
Typ.
O 1/2" (13mm)
Anchor Bolts (Typ.)
4 legs furnished for 1, 2, & 3 fan models
6 legs furnished for 4 fan models
A
DETAIL A
1"
25mm
1"
25mm
4 1/4"
108mm
4 1/4"
108mm
O
9/16"
14mm
Typ.
1 3/4"
44mm
1 3/4"
44mm
1 7/8"
48mm
1 7/8"
48mm
Notes:
1. All Drycooler fan motors are 1/4H.P.
2. A miniimum clearance of 36" (914mm) is recommended on all sides for proper operation and component access.
41 1/4"
1046mm
