Vertiv Liebert EXM - 2.5.1 Dimensions; 2.5.2 Clearances

Vertiv™ | Liebert® EXM
™
50-250kVA, 480V, 60Hz User Manual | 13
2.5.1 Dimensions
Figure 1 UPS dimensions
2.5.2 Clearances
78.75"
(2000mm)
23.6" (600mm)
50-200kVA Models 250kVA Models
I/O
Section
78.75"
(2000mm)
33" (840mm)
Liebert
EXM
0 to 5" (127mm)
Rear clearance
depends on
anchoring method
0" Required
Minimum of 36" (914mm) required
for foot traffic with door fully open
FRONT
REAR
0" Required
