Vertiv™ | Liebert® EXM
™
50-250kVA, 480V, 60Hz User Manual | 49
5.0 OPTION INSTALLATION
5.1 Liebert® IntelliSlot™ Communication
The Liebert
®
EXM
™
has three Liebert
®
IntelliSlot
™
ports to allow field-installation of optional
communication cards. Liebert
®
IntelliSlot
™
cards communicate via Vertiv’s
™
proprietary Velocity
™
protocol to cards that translate the information into such protocols as SNMP and Modbus. Other
cards provide dry contact signals for external signaling of operating status.
The Liebert
®
IntelliSlot
™
communication ports may be installed or removed while the Liebert
®
EXM
™
is operating.
5.2 Liebert® IntelliSlot™ Web Card—SNMP/HTTP Network Interface Card
This network interface card provides all real-time data and status information as SNMPv1 traps
for connection to a 10/100-baseT Ethernet connection. The same card also will transmit the same
status information and all measured parameters for display via a Web browser. The Liebert
®
IntelliSlot
™
bays are on the right side of the control module and labeled as IntelliSlot1, IntelliSlot2
and IntelliSlot3.
5.2.1 Liebert® IntelliSlot™ Unity Cards—IS-UNITY-LIFE™, IS-UNITY-DP™
•IS-UNITY-LIFE
™
: This standard card is used for communication between the Liebert
®
EXM
™
and Vertiv’s
™
Trellis
™
NMS and LIFE
™
services.
•IS-UNITY-DP
™
: This card can be used instead of the standard card if communication to two third-party
platforms is required. Third-party platforms include SNMP and 485 (Modbus/BACnet) protocols. This
card would still be used for communication between the Liebert
®
EXM
™
and Vertiv’s
™
Trellis
™
NMS and
LIFE
™
Services. All communication protocols are active simultaneously.
•Liebert
®
IntelliSlot
™
Dry Contact Card (IS-RELAY): Provides dry contact alarm information, including: On
Battery, On Bypass, Low Battery, Summary Alarm, UPS Fault and On UPS signals for communication to a
remote monitoring system or for use with Liebert
®
MultiLink
®
software.
•IS-485EXI
™
: The Liebert
®
IntelliSlot
™
485 EXI Card provides connection to a Liebert
®
SiteLink-E
™
allowing
Liebert
®
SiteScan
®
Web 4.0 monitoring and control of your Liebert
®
equipment.
Table 9 Liebert® EXM™ communication options
Port Type and
Location
Labeled ID
Name of Port
Monitoring
Devices Supported
Left
Liebert
®
IntelliSlot
™
Liebert
®
IntelliSlot
™
1
IS-Relay
IS-Unity-DP *
IS-Unity-LIFE *
IS-485EXI *
Center
Liebert
®
IntelliSlot
™
Liebert
®
IntelliSlot
™
2
IS-Relay
IS-Unity-DP
IS-Unity-LIFE
IS-485EXI
Right
Liebert
®
IntelliSlot
™
Liebert
®
IntelliSlot
™
3
IS-Relay
IS-Unity-DP
IS-Unity-LIFE
IS-485EXI
* Not applicable to HMI with push button controls
