Figure 18 Input dry contacts
J26
2468
10 12
14
16 18 20
22 24
26
28
30 32
GEN MODE
+12V_DRY
Reserved
GND_DRY
GND_DRY
TMP BATT_IN
ENV_DET
GND_DR
Y
CHG SHUT
GND_DRY
RESV1
UT2 485+
UT2 485-
GND_DRY
NC
NC
135791113151719212325272931
Q1 STATUS
GND_DRY
Q2 STATUS
GND_DRY
Q3 STATUS
GND_DRY
Q5 STATUS
GND_DRY
GND_DRY
RESV2
RESV3
GND_DRY
UT1 485+
GND_MON
UT1 485-
NC
