Vertiv Liebert EXM - Table 18 UPS Currents and Terminals-Bypass, Dual-Input Unit, 480 V Operation; Table 19 UPS Currents and Terminals-Output

Vertiv™ | Liebert® EXM
™
50-250kVA, 480V, 60Hz User Manual | 75
Table 18 UPS currents and terminals—Bypass, dual-input unit, 480V operation
Unit
Ratin
g
Nominal
Input
Current
Maximum
Input
Current
OCP
Device
Rating
Bol
t
Siz
e
75°C Wire
Current,
Total
Copp
er
Wire
Aluminu
m
Wire
50 60 60 80
M1
2
85 (1) #4 (1) #2
100 120 120 150
M1
2
150 (1) 1/0 (1) 3/0
150 180 180 225
M1
2
230 (1) 4/0 (2) 1/0
200 241 241 300
M1
2
350
(2)
2/0
(2) 3/0
250 301 301 400
M1
2
460
(2)
4/0
(2) 250
Wire sized for operation at 40°C
Table 19 UPS currents and terminals—Output
Unit
Ratin
g
Nominal
Input
Current
Maximum
Input
Current
OCP
Device
Rating
Bol
t
Siz
e
75°C Wire
Current,
Total
Copp
er
Wire
Aluminu
m
Wire
50 60 60 80
M1
2
85 (1) #4 (1) #2
100 120 120 150
M1
2
150 (1) 1/0 (1) 3/0
150 180 180 225
M1
2
230 (1) 4/0 (2) 1/0
200 241 241 300
M1
2
350
(2)
2/0
(2) 3/0
250 301 301 400
M1
2
460
(2)
4/0
(2) 250
Wire sized for operation at 40°C.
Table 20 UPS currents and terminals—DC input
Unit
Ratin
g
Maximum
Input
Current
OCP
Device
Rating
Bolt
Size
75°C Wire
Current,
Total
Coppe
r
Wire
50 145 150 M12 230 (1) 4/0
100 290 300 M12 460 (2) 3/0
150 435 450 M12 690 (3) 3/0
200 581 600 M12 765
(3)
250
250 726 800 M12 930
(3)
350
Wire sized for operation at 40°C.
NOTE
A Liebert
®
BIB is required for shunt trip of the customer-supplied breaker for the external DC
source. Refer to SL-25656, available at Vertiv’s
™
Web site, www.vertivco.com, for details.
