Vertiv™ | Liebert® EXM
™
50-250kVA, 480V, 60Hz User Manual | 43
Figure 24 UPS main components—Typical 50-200kVA unit
Replaceable
A
ir Filters
Replaceable
Air Filter
Control
Panel
Power
Modules
Fuse Holders
Static Bypass
Assembly
Bypass
Fuses
Rectifier
Fuses
