2.8 Static Bypass Assembly
Figure 6 Static Bypass Assembly connections
The Control Module has three Liebert
®
IntelliSlot
™
interface card bays and connections for
optional ancillary cabinets and for other options. Refer to Figures 16 through 19.
Liebert IntelliSlot
Bays 1, 2, 3
Ready Switch
DB9
DB9
DB15
See Figures 17- 20 for details.
