Vertiv | Liebert PEX4 | User Manual 43
Installation
No. Description
1 Bolt
Figure 2-26 Position of Fixing Bolt
5. Install the xing bolts, as shown in Figure 2-26 with total 4 PCS of bolts holding the arrangement tight during
operation.
No. Description No. Description
1 Base pallet of unit 3 Bolt
2 Top cover of fan
Figure 2-27 Lowered Fan
