Vertiv | SmartAisle2 | User Manual 9
Introduction
The typical configuration list of SmartAisle2 is described in Table 1-5.
Table 1-5 Typical configuration list
Classification Project Product number Quantity Remark
Cabinets
600 mm wide server cabinet SR-E061120T 24 Nos
800 mm wide server cabinet SR-E081120T 1 set
800 mm wide network cabinet SR-E081120T 1 set
Cabinet
Accessories
Cabinet side panel E-1120S 1 set
Vertical cable management panel IRS-A-CV / E 12 sets
Windshield side cabinet / 2 sets
Rectangular cable management unit IRS-A-CR 16 Nos
Fixed light load tray IRS-A-SFL 24 Nos
1U Blind IRS-A-B1 24 sets
2U blanking plate IRS-A-B2 24 sets
3U Blind IRS-A-B3 24 sets
1U blind plate with a brush IRS-A-B1P 24 sets
PDU IRS-PL30NN32 46 Nos
Cooling
Indoor air conditioning unit CR035RA138SS12E10000PV000 4 Nos
Air Conditioners
LSF42-R3 – Option 1 4 Nos
35 °C ambient
temperature
LSF52-R3 – Option 2 4 Nos
40 °C ambient
temperature
LSF76-R3 – Option 3 4 Nos
45 °C ambient
temperature
Monitoring Card ES025RA SIC card assembly 4 pieces
Supply and
distribution
Distribution Cabinet / 2 Nos
Channel closed
Access door SA-D1220SEY 1 set
600 mm open skylight SA-TR0612P 13 Nos
800 mm open skylight SA-TR0812P 1 item
SPM open skylight SA-TP0612P 1 item
The traces
Strong cross-channel electrical
trunking
SA-WAQ121210 1 item
Weak trough cross-channel SA-WAR122610 1 item
Roof slot width 600 mm SA-WR06103009 28 Nos
800 mm Roof wide groove SA-WR08103009 2 pieces
Base
600 mm wide base SA-SR061125 28 Nos
800 mm wide base SA-SR081125 2 pieces
The base access door SA-SD121125 1 set
Positioning the base member SA-SF121125 6 pieces
Administration
Kit
Administration Kit SA-MP 1 set
Lighting Kit SA-LP12C 1 set
Kit control panel SA-DP15 1 set
