LaserCOMPACT Product Guide VESDA
®
2
Features of the LaserCOMPACT
The LaserCOMPACT features make it an ideal smoke detection apparatus for protecting small
environments and individual objects:
• Reduced size compared to LaserPLUS and LaserSCANNER detectors
• Wide sens
itivity range
•
Each detector can cover an area of up to 800 m
2
(8000 sq. ft.)
• Up to three programmable alarm thresholds
• Programmable relays
• AutoLearn feature
• One pipe inlet that can be split into two pipes
• Dual stage air filter cartrid
ge
•
Option for inverted mounting
• High efficiency aspirator
• Airflow monitoring
• Optional remote display and relay capability
• Active fault monitoring
• Easy cable termination
• Event log to 12000 events
• RO Version: Relay Only version for stand alone LaserCOMPACT
• VN Version: VESDAnet (VN) version for networked LaserCOMPACT
• Remote modules available (VN version only) to meet site specific requirements
• Three programmable general purpose input functions
• PC capable programming and monitoring
1.3 Operation of the LaserCOMPACT
An air sampling pipe network collects air samples from a protected area. The VESDA integrated
aspirator draws air into the sampling pipes through a pipe inlet manifold. For further information
on air sampling pipe networks please see the Pipe Network Design and Installation Manuals.
Some of this air flows to the dual stage filter. The first stage air filter removes dust and dirt from
the sampled air and flows to the laser detector chamber to detect the presence of smoke.
