1.4 Product Information
Product Specification
Supply Voltage 18 to 30 VDC
Power Consumption 5.4 W during normal operation, 5.9 W with alarm on
Current Consumption 225 mA at 24 VDC normal operation, 245 mA with alarm on
Fuse Rating 1.6A
Dimensions (WHD) 225 mm x 22 5 mm x 85 mm (8 7/8 in x 8 7/8 in x 3 3/8 in)
Weight 1.9kg (4.2 lbs)
Operating Temperature
(To operate the
LaserCOMPACT detector
outside these parameters
please contact your
nearest VESDA Office)
Detector Ambient:
UL tested: 0° to 39° C (32° F to 103° F)
Sampled Air: -20° to 60° C (-4° to 140° F)
Humidity: 10-95% RH, non-condensing
Storage Temperatures
(Non-operational)
Up to 2 years (battery life). 0° to 85° C
Dry (<95% humidity),
0° to 85° C,
Must not exposed to sunlight or other radiation sources
Sampling Pipe Network
Maximum area of coverage: 800 m
2
(8000 sq. ft.)
Maximum Single Pipe Length: 80 m (max. 20 holes)
Maximum branched (2) Pipe Lengths: 50 m each (max. 20 holes)
Computer Design Tool: ASPIRE™
Pipe Size ID: 15-21 mm (0.874 in)
OD: 25 mm (1.050 in.)
Relays 3 relays, contacts rated 2A @ 30 VDC
Programmable to latched or non-latched states
Relays Default
Configuration
Fire
Pre-Alarm
Alert/Fault (Maintenance and Isolate)
Programmable 0 - 60 sec. time delay for each relay
IP Rating IP30
Cable Access 4 x 25 mm (1 in) cable entries
Cable Termination Screw terminal blocks (0.2-2.5 sq mm, 30-12 AWG)
Detector Resolution 0.005 to 20.00% obs/m
(0.0015 to 6.25% obs/ft.)
