LaserCOMPACT Product Guide
9
Product Configuration
Figure 5 - Front view of the LaserCOMPACT detector
Figure 6 - View of components in the enclosures box
Legend
A Reset/Isolate Button
B LED indicators
A
B
A
B
C
D
E
F
G
H
I
J
KL
Legend
A Programming socket
15 Pin for VN model
9 Pin for RO model
B Termination card
C VESDAnet number
D Air filter cartridge
EFilter screw
F Air exhaust port
G Aspirator
H 1.6 Amp fuse
I Anti tamper screw
J Cable entry ports
K Air inlet port
L Wire terminal strips
