LaserCOMPACT Product Guide VESDA
®
8
LCD Programmer
The VESDA LCD Programmer allows configuring, commissioning and maintenance of the
VESDA system. For further information please see the LCD Programmer Product Guide. A
hand-held programmer can be connected to the LaserCOMPACT VN Models (VLC-505). The
VESDAnet socket and VESDAnet terminals can be found on the termination card and can be
accessed by removing the front cover of the detector. A LCD Programmer mounted into a remote
Unit or a 19” Sub-Rack may also be used (for VLC500 models see ‘Programming socket” on
page 22).
Figure 4 - LCD programmer
Legend
A Display
BKeys
