Compact (VN) Remote Display Module
The LaserCOMPACT (VN) model has the option of being connected to a Remote Display Module
mounted into a Mounting Unit or a 19” Subrack. Unlike the LaserPLUS and the LaserSCANNER
detectors, the display module cannot be mounted into the LaserCOMPACT.
Figure 3 - VRT-J00 Display Module mounted into a remote unit
B
A
C
D
E
F
Legend
A Threshold Indicators
B Bar graph
C Numerical Display
D Alarm Level LEDs
E Fault LEDs
F Push Button Keys
