VESDA LaserCOMPACT - Internal Wiring; Spare Parts

VESDA
®
LaserCOMPACT Product Guide
31
Internal wiring for LaserCOMPACT
The table below provides the cable loom interconnecting details inside the detector. Use the look
up table in conjunction with the attached circuit diagram to assist with maintenance.
Table 9 - Interconnecting loom details
1.13 Spare Parts
On larger sites having multiple detectors it is advisable to stock certain critical spare parts. A list
of spare parts with quantities required is given below:
Table 10 - Recommended spare parts stock
From To
Connector
Name on CPU
Cable Name # Pins
CPU card Detection chamber Pre-amp or X9 Pre Amp 6 Wire ribbon
CPU card Detection chamber Laser or X10 Laser 6
Termination
card
LED PCB LED card or X11 LED cable 7
Termination
card
Aspirator Aspirator or X12 Aspirator
cable
3
Part No. Description
Number of detectors Installed
to warrant ONE Spare Part
Normal
Service
Mission
Critical
VSP-005 Filter Cartridge 50 20
VSP-501 LaserCOMPACT Aspirator N/A 20
VSP-502 LaserCOMPACT VN Remote Display Module 50 20
VSP-510 LaserCOMPACT RO Termination Card (CTC-RO) 50 20
VSP-515 LaserCOMPACT VN Termination Card (CTC-VN) 50 20
