Vespa LX 50 Workshop Manual

Removal of the engine from the vehicle
Removing the engine from the frame
-Disconnect the battery.
-Remove the muffler assembly.
- Remove the rear wheel.
- Remove the mechanical transmission of the rear brake.
-Disconnect the electric terminals.
- Remove the throttle grip and mixer transmissions.
- Disconnect the hoses (petrol-oil-vacuum-operated cock control).
WARNING
Be very careful when handling fuel.
CAUTION
When installing the battery, first attach the positive cable and then the negative cable.
WARNING
Wear safety goggles when using hitting tools.
Vespa LX 50 Engine from vehicle
ENG VE - 59

Vespa LX 50 Specifications

General

Engine Type	Single-cylinder, 4-stroke
Displacement	49.9 cc
Fuel System	Carburetor
Front Brake	200 mm disc
Rear Brake	110 mm drum
Seat Height	785 mm
Fuel Tank Capacity	8.6 liters
Tires Front	110/70 - 11"
Tires Rear	120/70 - 10"
Length	1, 770 mm
Width	705 mm
Cooling System	Air cooled
Transmission	Automatic
Max Power	3.2 kW
Max Torque	4.2 Nm
