Vespa LX 50 Workshop Manual

- Use new wrist pin snap rings.
- Use new cylinder base gasket.
- Before refitting carefully clean all the surfaces.
- Use oil to be mixed during the fitting of the piston
and the cylinder.
CAUTION
POSITION THE ARROW PRINTED ON THE PISTON
CROWN TOWARDS THE EXHAUST OPENING.
THE WRIST PIN SNAP RINGS MUST BE POSITIONED ON
THE PISTON WITH THE SPECIFIC TOOL
Recommended products
AGIP CITY TEC 2T Oil
Recommended oil
Engine Vespa LX 50
ENG - 82

Vespa LX 50 Specifications

General

Engine Type	Single-cylinder, 4-stroke
Displacement	49.9 cc
Fuel System	Carburetor
Front Brake	200 mm disc
Rear Brake	110 mm drum
Seat Height	785 mm
Fuel Tank Capacity	8.6 liters
Tires Front	110/70 - 11"
Tires Rear	120/70 - 10"
Length	1, 770 mm
Width	705 mm
Cooling System	Air cooled
Transmission	Automatic
Max Power	3.2 kW
Max Torque	4.2 Nm
