Diagnostics
Diagnostic Procedures
The DSOE301, DDOE301, and DDOE305 use the same clock (TOD2) but because of the programming, the
actual buttons are labeled differently on the control panel. Below are examples showing both clocks.
For the following procedures, the clock from the DSOE301/DDOE301 is being used as the example. In this
manual, we will refer to (from left to right) Button 1 —Button 2—(SET KNOB)—Button 3 and Button 4.
User Settings
To enter into Settings parameter, press and hold “BUTTON 1” for three seconds. When the Settings mode is
entered, the clock display will change to the first parameter (Temperature). To exit the Settings mode, press
“BUTTON 2”.
Note: Settings mode will automatically exit the Settings mode if nothing is pressed within 60 seconds.
Degrees
The “F” indicates that the unit is set to display fahrenheit (below left). To change to celsius, depress
“BUTTON 1”. The unit set for celsius is shown (below right).
DSOE301/DDOE301
DDOE305
1 2 3 4
SET
DSOE301/DDOE301
DDOE305
1 2 3 4
SET
