24
Diagnostics
Component Testing (cont.)
240 Volts 208 Volts
Current (AMPS) Current (AMPS)
Convection Fan Lo F
Press “BUTTON 1”
to operate the
Conv fan low.
Cooling Fan High
Press “BUTTON 1”
to operate
Cooling fan high.
Cooling Fan Low
Press “BUTTON 1”
to operate Cooling
fan low.
Note: Same speed as
High fan.
RPM’s
Cooling Fan
High Speed–RPM
When “BUTTON 1” is
depressed, cooling fan
comes on and the RPM’S
are shown in the display.
Cooling Fan
Low Speed–RPM
Note: The DDOE301 and
DSOE301 use a single
speed fan. The results will
be the same as high
speed.
Lights–Oven
This parameter will cycle
the EOC light relay ON
and OFF with each press
of “BUTTON 1”, as well
as the display showing
the status.
Press
“BUTTON 1”
Press
“BUTTON 1”
Press
“BUTTON 1”
