Viking DSOE301SS - Page 29

© 2010 Viking Preferred Service
29
Service Diagnostics and Procedures
Control boards (cont.)
Thermostat–(P14) Orange–(P14) Blue
Setting Resistance (Ω)
Off Infinite
200 4.4K
225 4.3K
250 4.2K
275 4.1K
300 3.9K
325 3.8K
350 3.6K
375 3.4K
400 3.2K
425 2.9K
450 2.7K
475 2.4K
500 2.1K
525 1922
Broil 1527
1126
940
Clean 568
Lower Oven Thermostat–(P14) Orange–
(P14) Blue
Setting Resistance (Ω)
Off Infinite
200 1365
250 1820
300 2140
350 2310
400 2350
450 2260
500 1990
Broil 1530
Clean 565
Selector–(P14) Black–(P14) Yellow
Setting Resistance (Ω)
Off Infinite
Self-Clean 453
Low Broil 1521
Medium Broil 2.4K
Hi Broil 3.2K
Convection Broil 3.8K
Convection Roast 4.2K
TrueConv 4.5K
Convection Bake 4.6K
Bake 4.6K
Lower Oven Selector–(P14) Black–
(P14) Yellow
Setting Resistance (Ω)
Off Infinite
Self-Clean 981
Low Broil 1890
Medium Broil 2230
Hi Broil 1960
Bake 1190
Control board LED’s
D12 – K3 Relay (L1) D23 – Inner Bake
D13 – K4 Relay
(Door Lock Motor)
D24 – Outer Bake
D14 – K5 Relay
(Oven Light)
D25 – Inner Broil
D19 – K6 Relay
(Convection Speed Lo)
D26 – Convection
D20 – K8 Relay
(Cooling Fan Power)
D27 – Outer Broil
D21 – K7 Relay
(Convection Speed Hi)
D30 – Line Break
D22 – K9 Relay
(Cooling Fan Speed)
