~ 10 ~
SPOOL PINS
HORIZONTAL SPOOL PIN for normal thread spool
Place thread spool on the pin and secure with a spool cap
to ensure smooth Á ow of thread.
VERTICAL SPOOL PIN for large thread spool
1. Place the removable thread guide on the horizontal spool
pin as illustrated.
2. Pull the base of the spool pin down, then pull up the
spool pin. Pull up the thread guide on base of the
horizontal spool pin..
3. Place thread spool on the vertical spool pin and pull
the thread through the thread guide and through the
removable thread guide.
Spool pin cap
Spool Spool pin
Removable
thread guide
Thread guide
Vertical spool pin
For large thread spool For extra large thread spool
1
2
3
