~ 25 ~4. Sewing
ZIGZAG
Settings: Presser foot - Utility Foot,
Thread tension dial - S - E
The top thread may appear on the bottom depending on
the thread, fabric, type of stitch and sewing speed, but the
bobbin thread must never appear on top of the fabric.
Under side
Top side
SATIN STITCH
Closely spaced zig-zag stitches are called satin stitches.
This is an attractive stitch used primarily for appliqués and
bar tacking. Slightly loosen top thread tension for satin
stitching. Use a backing of stabilizer or interfacing to avoid
puckering.
Set length between 0.5 and 2.0.
Placement of Patterns
Stitch width of pattern increases from center needle
position as illustrated.
Satin Stitch Foot
The Satin Stitch Foot is grooved on the bottom to permit
dense stitching to pass under it easily. It is most useful for
sewing satin stitches. It can also be used as an alternative to
the Utility Foot when sewing stretch stitches.
Center position
eng manual rev1.indd 25 2009-11-24 11:12:45
