~ 44 ~
ATTACH AND REMOVE THE
EMBROIDERY HOOP
1. Raise the presser foot and needle, and push up lever
(A) of embroidery foot with your À nger and pass
embroidery hoop under it.
To remove, pull the hoop forward to slide it out from
underneath the embroidery foot.
2. Attach the hoop to the embroidery unit by aligning the
hoop attachment screws (D) and the grooves in the
hoop mounting plate, À tting projections (C) on the hoop
bracket into the square holes (B) in the hoop mounting
plate. Securely tighten the hoop attachement screws (D)
with a screwdriver.
To remove, loosen hoop attachment screws (D) and
remove the hoop from the hoop bracket.
Note: Before attaching small hoop, turn on power switch to move the
carriage to embroidering standby position.
Hoop mounting plate
Embroidery
arm
A
B
C
D
B
D
