~ 23 ~4. Sewing
3/4" (19
mm
)
5/8" (16
mm
)
1/2" (13
mm
)
3/8" (9
mm
)
1/4" (6
mm
)
Turning a Square Corner
1. To turn a square corner 5/8" (16 mm) from the fabric
edge, push the needle stop up/down button to stop the
needle in its lowest position. Start and stop the machine
when reaching the cornering guide as shown. Raise the
presser foot and turn fabric.
2. New stitching line will align with 5/8” (16 mm) seam
guide on side of needle plate. Lower the presser foot and
begin stitching in new direction.
Cornering guide
Needle Stop
Up/Down
Keeping Seams Straight
To keep the seam straight, use one of the numbered guide
lines on the needle plate. The numbers indicate distance
from the needle at its center position.
The guide line on the bobbin cover plate is 1/4" (6mm)
seam guide line which is used for piecing quilt blocks and
also for narrow seams, such as those in doll clothes or baby
garments.
