Event ID Description
0x04: SafeOp
0x08: Op
ZInfo2 : Diagnostic address of the master
ZInfo3 : Number of stations, which are not in the same state as the master
DatID : Input address
DatID : Output address
DatID : Station not available
DatID : Station available
0xED12 EtherCAT: Slave failure
ZInfo1 : Old status
0x00: Undefined/Unkown
0x01: INIT
0x02: PreOp
0x03: BootStrap
0x04: SafeOp
0x08: Op
ZInfo1 : New status
0x00: Undefined/Unkown
0x01: INIT
0x02: PreOp
0x03: BootStrap
0x04: SafeOp
0x08: Op
ZInfo2 : Diagnostics address of the station
ZInfo3 : AlStatusCode
0x0000: No Error
0x0001: Unspecified error
0x0011: Invalid requested status change
0x0012: Unknown requested status
0x0013: Bootstrap not supported
0x0014: No valid firmware
0x0015: Invalid mailbox configuration
0x0016: Invalid mailbox configuration
0x0017: Invalid sync manager configuration
0x0018: No valid inputs available
0x0019: No valid outputs available
0x001A: Synchronisation error
0x001B: Sync manager watchdog
VIPA System 300SDeployment CPU 314-6CF03
Diagnostic entries
HB140 | CPU | 314-6CF03 | GB | 16-43 118
