9 WinPLC7
9.1 System conception
WinPLC7 is a programming and simulation software from VIPA for
every PLC programmable with Siemens STEP
®
7. This tool allows you
to create user applications in FBD, LAD and STL. Besides of a com-
fortable programming environment, WinPLC7 has an integrated simu-
lator that enables the simulation of your user application at the PC
without additional hardware. This "Soft-PLC" is handled like a real
PLC and offers the same error behavior and diagnostics options via
diagnostics buffer, USTACK and BSTACK.
Detailed information and programming samples may
be found at the online help respectively in the online
documentation of W
inPLC7.
There is also the possibility to use according configuration tools from
Siemens instead of WinPLC7 from VIPA. Here the proceeding is part
of this manual.
n Windows XP (SP3)
n Windows V
ista
n Windows 7 (32 and 64 bit)
n Windows 8 (32 and 64 bit)
You may receive a demo version from VIP
A. Without any activation
with the demo version the CPUs 11x of the System 100V from VIPA
may be configured. To configure the SPEED7 CPUs a license for the
"profi" version is necessary. This may be online be received from
VIPA and activated.
There are the following sources to get WinPLC7:
n Online
–
At www.vipa.com in the service area at Downloads a link to the
current demo version and the updates of WinPLC7 may be
found.
n CD
– SW211C1DD: WinPLC7 Single license, CD, with documenta-
tion in German
– SW211C1ED: WinPLC7 Single license, CD, with documenta-
tion in English
9.2 Installation
The project engineering of a SPEED7 CPU from VIP
A with WinPLC7
is only possible using an activated "Profi" version of WinPLC7.
General
Alternatives
System requirements
Source
Precondition
VIPA System 300S WinPLC7
Installation
HB140 | CPU | 314-6CF03 | GB | 16-43 205
