Event ID Description
ZInfo2 : EtherCAT station address
0xEE00 Additional information at UNDEF_OPCODE
ZInfo1 : Not relevant to the user
ZInfo2 : Not relevant to the user
ZInfo3 : Not relevant to the user
OB : Not relevant to the user
DatID : Not relevant to the user
0xEE01 Internal error - Please contact the hotline!
0xEEEE CPU was completely overall reset, since after PowerON the start-up could not be finished
0xEF00 Internal error - Please contact the hotline!
0xEF01 Internal error - Please contact the hotline!
0xEF11 Internal error - Please contact the hotline!
0xEF12 Internal error - Please contact the hotline!
0xEF13 Internal error - Please contact the hotline!
0xEFFE Internal error - Please contact the hotline!
0xEFFF Internal error - Please contact the hotline!
5.21 Control and monitoring of variables with test functions
For troubleshooting purposes and to display the status of certain vari-
ables you can access certain test functions via the menu item Debug
of the Siemens SIMA
TIC Manager.
n The status of the operands and the RLO can be displayed by
means of the test function ‘Debug è Monitor’.
n The status of the operands and the RLO can be displayed by
means of the test function ‘PLC è Monitor/Modify Variables’.
This test function displays the current status and the RLO of the dif-
ferent operands while the program is being executed. It is also pos-
sible to enter corrections to the program.
When using the test function "Monitor" the PLC must
be in RUN mode!
Overview
‘Debug è Monitor
’
VIPA System 300S Deployment CPU 314-6CF03
Control and monitoring of variables with test functions
HB140 | CPU | 314-6CF03 | GB | 16-43 127
