5.7 Hardware configuration - SPEED-Bus
5.7.1
Preconditions
Since the VIPA specific CPU parameters may be set and the modules
at the SPEED-Bus may be configured, the installation of the
SPEEDBUS.GSD from VIPA in the hardware catalog is necessary.
The CPU and its SPEED-Bus modules may be configured in a
PROFIBUS master after installation.
The GSD (Geräte-Stamm-Datei) is online available in the following
language versions. Further language versions are available on
inquires:
Name Language
SPEEDBUS.GSD German (default)
SPEEDBUS.GSG German
SPEEDBUS.GSE English
The GSD files may be found at www.vipa.com at the "Service" part.
The integration of the SPEEDBUS.GSD takes place with the following
proceeding:
1. Browse to www
.vipa.com
2.
Click to ‘Service è Download è GSD- and EDS-Files
è Profibus’
3. Download the file Cx000023_Vxxx.
4. Extract the file to your work directory. The SPEEDBUS.GSD is
stored in the directory VIPA_System_300S.
5. Start the hardware configurator from Siemens.
6. Close every project.
7.
Select ‘Options è Install new GSD-file’.
8. Navigate to the directory VIP
A_System_300S and select
SPEEDBUS.GSD an.
ð
The SPEED7 CPUs and modules of the System 300S from
VIPA may now be found in the hardware catalog at
PROFIBUS-DP / Additional field devices / I/O /
VIPA_SPEEDBUS.
Installation of the
SPEEDBUS.GSD
VIPA System 300S Deployment CPU 314-6CF03
Hardware configuration - SPEED-Bus > Preconditions
HB140 | CPU | 314-6CF03 | GB | 16-43 63
