Event ID Description
0x08: Op
ZInfo2 : Diagnostics address of the master
ZInfo3 : Number of stations, which are not in the same state as the master
DatID : Input address
DatID : Output address
DatID : Station not available
DatID : Station available
0xED21 EtherCAT: Faulty bus status change
ZInfo1 : Old status
0x00: Undefined/Unkown
0x01: INIT
0x02: PreOp
0x03: BootStrap
0x04: SafeOp
0x08: Op
ZInfo1 : New status
0x00: Undefined/Unkown
0x01: INIT
0x02: PreOp
0x03: BootStrap
0x04: SafeOp
0x08: Op
ZInfo2 : Diagnostics address of the master
ZInfo3 : Error code
0x0008: Busy
0x000B: Invalid parameters
0x000E: Invalid status
0x0010: Timeout
0x0004: Abbort (master state change)
DatID : Input address
DatID : Output address
DatID : Station not available
DatID : Station available
0xED22 EtherCAT: Slave state change without calling OB86
ZInfo1 : Old status
0x00: Undefined/Unkown
0x01: INIT
0x02: PreOp
VIPA System 300SDeployment CPU 314-6CF03
Diagnostic entries
