Event ID Description
0x0033: Invalid DC IO error
0x0034: Invalid DC timeout error
0x0042: Error in acyclic data exchange Ethernet over EtherCAT
0x0043: Error in acyclic data exchange CAN over EtherCAT
0x0044: Error in acyclic data exchange file access over EtherCAT
0x0045: Error in acyclic data exchange servo drive profile over EtherCAT
0x004F: Error in acyclic data exchange vendor specific over EtherCAT
DatID : Input address
DatID : Output address
DatID : Station not available
DatID : Station available
0xED23 EtherCAT: Timeout while changing the master status to OP, after CPU has changed to RUN
OB : Operation mode
0: Configuration in operation mode RUN
1: STOP (update)
2: STOP (overall reset)
3: STOP (own initialization)
4: STOP (internal)
5: Start-up (cold start)
6: Start-up (cold restart/warm start)
7: Start-up (restart)
8: RUN
9: RUN (redundant operation)
10: HALT
11: COUPLING
12: UPDATING
13: DEFECTIVE
14: Troubleshooting
15: Without power
0xFD: Process image enabled in STOP
0xFE: Watchdog
0xFF: Not set
ZInfo1 : Master status
0x00: Undefined/Unkown
0x01: INIT
0x02: PreOp
0x03: BootStrap
0x04: SafeOp
VIPA System 300SDeployment CPU 314-6CF03
Diagnostic entries
HB140 | CPU | 314-6CF03 | GB | 16-43 122
