Addr. Name Byte Function
+6 AI_CH1 2 Analog input CH1
+8 AI_CH2 2 Analog input CH2
+10 AI_CH3 2 Analog input CH3
+12 AI_CH4 2 Analog input CH4
+14 - 2 reserved
+16 CVCL_0 4 Counter/Latch value 0
+20 - 2 reserved
+22 ISTS_0 2 Input status counter 0
+24 CVCL_1 4 Counter/Latch value 1
+28 - 2 reserved
+30 ISTS_1 2 Input status counter 1
+32 CVCL_2 4 Counter/Latch value 2
+36 - 2 reserved
+38 ISTS_2 2 Input status counter 2
+40 CVCL_3 4 Counter/Latch value 3
+44 - 2 reserved
+46 ISTS_3 2 Input status counter 3
Output area
Addr. Name Byte Function
+0 - 1 reserved
+1 DO_1 1 Digital output Q+1.0 ... Q+1.7
+2 - 2 reserved
+4 AO_CH0 2 Analog output CH0
+6 AO_CH1 2 Analog output CH1
+8 - 2 reserved
+10 OSTS_0 2 Output status counter 0
+12 - 2 reserved
+14 OSTS_1 2 Output status counter 1
+16 - 2 reserved
+18 OSTS_2 2 Output status counter 2
+20 - 2 reserved
+22 OSTS_3 2 Output status counter 3
VIPA System 300S Deployment I/O periphery
Address assignment I/O part
HB140 | CPU | 314-6CF03 | GB | 16-43 133
