n Function no.
–
Here you set the function no. of your measuring respectively
output function for every channel. These can be found in the
corresponding function no. assignment from the table for the
input respectively output area.
n Measuring cycle
– Here you may set the transducer velocity for every input
channel. Please regard that a higher transducer velocity
causes a lower resolution because of the lower integration
time. The data transfer format remains unchanged. Only the
lower bits (LSBs) are not longer relevant for the analog value.
Structure measuring cycle byte:
Byte Bit 7 ... 0 Default
7 ...
1
1
n Bit 3 ... 0: V
elocity per channel
– 0000: 15 conversions/s, resolution: 16
– 0001: 30 conversions/s, resolution: 16
– 0010: 60 conversions/s, resolution: 15
– 0011: 120 conversions/s, resolution: 14
– 0100: 170 conversions/s, resolution: 12
– 0101: 200 conversions/s, resolution: 10
– 0110: 3.7 conversions/s, resolution: 16
– 0111: 7.5 conversions/s, resolution: 16
n Bit 7 ... 4: reserved
00h
Input area (channel 0 ... 3)
No. Function Input area
19h Voltage ±10V
S7 format from Siemens
±11.76V
1
1.76V= End overdrive region (32511)
-10...10V = Nominal range (-27648 ... 27648)
-11.76V = End underdrive region (-32512)
two’s complement
18h Voltage 0...10V
S7 format from Siemens
0...11.76V
1
1.76V = End overdrive region (32511)
0...10V = Nominal range (0 ... 27648)
no underdrive region available
24h Current ±20mA
S7 format from Siemens
±23.52mA
23.52mA = End overdrive region (3251
1)
-20...20mA = Nominal range (-27648 ... 27648)
-23.52mA = End underdrive region (-32512)
two’s complement
Function no. assign-
ment
VIPA System 300SDeployment I/O periphery
Analog part - Parametrization
HB140 | CPU | 314-6CF03 | GB | 16-43 140
