Order no. 314-6CF03
Max. capacitive load (current range) 1 µF
Max. inductive load (current range) 30 mA
Output voltage ranges -10 V ... +10 V
0 V ... +10 V
Operational limit of voltage ranges +/-0.4%
Basic error limit voltage ranges with SFU +/-0.3%
Destruction limit against external applied
voltage
max. 15V
Current outputs
ü
Max. in load resistance (current range) 500 Ω
Max. inductive load (current range) 10 mH
Typ. open circuit voltage current output 16 V
Output current ranges -20 mA ... +20 mA
0 mA ... +20 mA
+4 mA ... +20 mA
Operational limit of current ranges +/-0.4%
Radical error limit current ranges with SFU +/-0.3%
Destruction limit against external applied
voltage
max. 15V
Settling time for ohmic load 0.2 ms
Settling time for capacitive load 0.5 ms
Settling time for inductive load 0.75 ms
Resolution in bit 12
Conversion time 1 ms
Substitute value can be applied yes
Output data size 4 Byte
Technical data counters
Number of counters 4
Counter width 32 Bit
Maximum input frequency 100 kHz
Maximum count frequency 100 kHz
Mode incremental encoder
ü
Mode pulse / direction
ü
Mode pulse
ü
Mode frequency counter -
VIPA System 300SHardware description
Technical data
