Order no. 314-6CF03
S7 communication
ü
S7 communication as server
ü
S7 communication as client -
Direct data exchange (slave-to-slave communi-
cation)
-
DPV1
ü
Transmission speed, min. 9.6 kbit/s
Transmission speed, max. 12 Mbit/s
Automatic detection of transmission speed -
Transfer memory inputs, max. 244 Byte
Transfer memory outputs, max. 244 Byte
Address areas, max. 32
User data per address area, max. 32 Byte
Point-to-point communication
PtP communication
ü
Interface isolated
ü
RS232 interface -
RS422 interface -
RS485 interface
ü
Connector Sub-D, 9-pin, female
Transmission speed, min. 150 bit/s
Transmission speed, max. 115.5 kbit/s
Cable length, max. 500 m
Point-to-point protocol
ASCII protocol
ü
STX/ETX protocol
ü
3964(R) protocol
ü
RK512 protocol -
USS master protocol
ü
Modbus master protocol
ü
Modbus slave protocol -
Special protocols -
Functionality RJ45 interfaces
Type X5
VIPA System 300SHardware description
Technical data
HB140 | CPU | 314-6CF03 | GB | 16-43 52
