SPEED-BUS
Slot 101 Module at the SPEED-Bus
VIPA 321-1BH70 V1.0.1 Px000029.pkg Name, firmware-version,
package
SUPPORTDATA :
BB000189 V1010, AB000076 V1010
PRODUCT V1010, Hx000013 V1000
ModuleT
ype 1FC20001
Address Input 128...131
Information for support
Slot 102 Module at the SPEED-Bus
VIPA 322-1BH70 V1.0.1 Px000030.pkg Name, firmware-version,
package
SUPPORTDATA :
BB000190 V1010, AB000077 V1000
PRODUCT V1010, Hx000014 V1000
ModuleT
ype AFD00001
Address Input 132...135
Information for support
...
Standard Bus
Standard Bus Modules at the standard bus
BaudRate Read Mode1, BaudRate Write Mode1 Information for support
Line 1: ModuleType 94F9: IM36x IM interface if exists
Rack 0 /Slot 4 Rack no. / slot
ModuleType: 9FC3: Digital Input 32
Baseaddress Input 0
Type of module
Configured base address
if exists firmware no. and
package
Rack 0 /Slot 5 ... Rack no. / slot
...
Line 2: ModuleType A4FE: IM36x IM interface if exists
Rack 1 /Slot 4
VIPA System 300SDeployment CPU 314-6CF03
Access to the internal Web page
HB140 | CPU | 314-6CF03 | GB | 16-43 80
