Vishay VT400 - Function Menu Operations and Summary; 3.3.2 Function Summary

Display, Keys and Menus
The Function Menu
VT400 Technical Manual, Rev. A5 25 Doc # UM-VT400-EN
3.3.2 Function Summary
Function Description Refer to
01
Edit setpoints. The display shows SEtP 1 briefly, then the current setpoint
value.
Use u (P.TARE) to change the current digit, then t (TARE) to move to the
next digit.
When you are done, press  (PRINT).
The display shows SEtP 2 briefly, then the current setpoint value.
Edit the second setpoint value using the same procedure.
Section 7.3
06 High resolution weighing. Increases the accuracy of the displayed weight
by a factor of ten, the lowest piece is limited to display division 1.
When this function is enabled, the display flashes and you may not print.
Press ZERO (
) to cancel and return to normal resolution.
-
20 Disable serial output. Prevents the indicator from printing when you press
PRINT (
), even if a printer is connected.
(Function activated only if setup parameter 2.8 is set to 1.)
-
21 Set print output format: Ticket. Shows weight in the following format:
GROSS:<00.500 kg>
(Function activated only if setup parameter 2.8 is set to 1.)
Section 6.2.1
22 Set print format: Continuous output. Used for external display or PC.
(Function activated only if setup parameter 2.8 is set to 1.)
Section 6.2.1
23 Set print format: Print on demand.
For gross weight: 00.300 kgG
For net weight: 00.300 kgG 00.100kgT 00.200kgN
(Function activated only if setup parameter 2.8 is set to 1.)
Section 6.2.1
30 Enable / disable host computer protocol output (EDP mode).
The display shows Pro...
Press PRINT to disable. The display shows Pro OFF briefly.
Press PRINT again to enable. The display shows Pro on briefly.
The selection is lost when the unit powers down.
Section 6.2.1
40 Changing PIN. Used to change the current Personal Identification Number
that enables access to the calibration procedure.
Section 8.1.1
