General System Parameters
SETUP 1 (Inside SETUP Menu)
VT400 Technical Manual, Rev. A5 42 Doc # UM-VT400-EN
5.2 SETUP 1 (Inside SETUP Menu)
5.2.1 Accessing the Menu and Editing Parameters
To access the SETUP 1 menu:
1. Turn on the unit.
2. During the self-test routine, while all display segments are on (all 8 on the
display), press PRINT (
) momentarily, followed by TARE ( ) momentarily.
Alternatively, press FUNCTION (
), and access function 49.
3. If the PIN code is activated, the display shows ACCESS briefly. Type the PIN
number and then PRINT (
) to get into the calibration menu. The display shows
SETUP.
4. Press PRINT (
) to enter the SETUP 1 menu.
To edit parameters in the SETUP 1 menu:
1. The current parameter number is shown on the display. Use PRINT (
) to scroll to
the parameter you need (see the following section for descriptions of parameters).
2. To edit the parameter value, use P.TARE ( ) to increment the current digit and
TARE (
) to move to the next digit.
3. When the display is showing the required value, press PRINT (
) to confirm your
selection.
5.2.2 SETUP 1 Parameters
Par. Description Values
1.1 Enable totalizer. YES enables the totalizer. NO disables it. 0=NO 1=YES
1.2 (Reserved for future use)
1.3
Lock ZERO key (
).
0=NO 1=YES
1.4
Lock TARE key (
).
0=NO 1=YES
1.5
Lock P.TARE key (
).
0=NO 1=YES
1.6
Lock PRINT key (
).
0=NO 1=YES
1.7
Lock TOTAL key (
).
0=NO 1=YES
1.8
Lock FUNCTION key (
).
0=NO 1=YES
