Vishay VT400 - SETUP > SETUP 3 (Com 2 Settings); SETUP > SETUP 4 (Tilt Switch)

Display, Keys and Menus
Setup Menus
VT400 Technical Manual, Rev. A5 30 Doc # UM-VT400-EN
SETUP > SETUP 3 (Com 2 Settings)
Par. Description Values
3.t Instrument communication type. 00=disabled; 01 =continuous weight output;
02=EDP protocol output; 03=printer protocol output;
65-90 [A-Z] =master/slave protocol address
3.1 Timeout control. 0=NO 1=YES
3.2 Handshake. 0=NO 1=YES
3.3 Operator disable. 0=NO 1=YES
3.4 Host enquiry. 0=NO 1=YES
3.5 Remote keyboard commands. 0=NO 1=YES
3.6 (Reserved for future use)
3.7 (Reserved for future use)
3.8 Debug. 0=NO 1=YES
3.b Baud rate serial number 2. 24=2400 bps
96=9600 bps
19=19200 bps
38=38400 bps
57=57600 bps
3.d Data bits serial channel 2. 17=7 data bits / even parity
08=8 data bits / no parity
18=8 data bits / even parity
SETUP > SETUP 4 (Tilt Switch)
Par. Description Values
4.t Time delay, after closing the contact, for the display to lock. This is also
the time for the display to unlock after the contact is opened.
This parameter has several special values:
• 91 – Tare scale on the rising edge of input. Setpoints always enabled.
• 92 – Print on the rising edge of the input. Setpoints always enabled.
• 93 – Setpoints active when input is high. Setpoints inactive when
input is low.
• 94 – Scale is tared at the rising edge of input. If taring is successful,
setpoints are activated. If input is low, setpoints are inactive.
• 95 – When input is low, scale 1 is selected and displayed. When input
is high, scale 2 is selected and displayed.
• 96 – Reset scale to zero.
00=disabled
01-90
(x 0.1 seconds)
91-96=special
options
