Outputs and Digital Input
Using the Tilt Switch
VT400 Technical Manual, Rev. A5 55 Doc # UM-VT400-EN
7.5 Using the Tilt Switch
You can set the time delay for the tilt switch function using the setup parameter 4.t.
Use this parameter to enter the time delay for display lock in 1/10 seconds. The delay
may be between 1 and 90 1/10 seconds (i.e. between 0.1 and 9 seconds).
When the contacts close, the display locks after the time delay elapses. When they
open again, the display unlocks after the same time delay elapses.
Set 4.t to 00 to disable the tilt-switch function.
7.5.1 Tilt Switch Options
Parameter 4.t, which controls the tilt switched, allows several special options,
accessed by setting it above 90:
91 – Tare scale on the rising edge of input. Setpoints always enabled.
92 – Print on the rising edge of the input. Setpoints always enabled.
93 – Setpoints active when input is high. Setpoints inactive when input is low.
94 – Scale is tared at the rising edge of input. If taring is successful, setpoints are
activated. If input is low, setpoints are inactive.
95 – When input is low, scale 1 is selected and displayed. When input is high,
scale 2 is selected and displayed.
96 – Scale is reset to zero.
