VOLTA FBW II Series User Manual

2. Technical Specifications
Table 1: FBW Welder System Specifications
FBW
301
FBW
721
FBW
1061
FBW
1301
FBW
1701
FBW
2101
Electricity
110 / 230 V
Single phase
400 W
110 / 230 V
Single phase
800 W
110 / 230 V
Single phase
1100 W
110/ 230 VAC
Single phase
1300 W
230 VAC
Single phase
1700 W
230 VAC
Single phase
2000 W
Maximum Current
110 VAC 3.7 amps 7.3 amps 10 amps 12 amps N/A N/A
230 VAC 1.8 amps 3.6 amps 5 amps 5.9 amps 7.4 amps 8.7 amps
Fuse
Type slow-blow slow-blow slow-blow slow-blow slow-blow slow-blow
110 VAC 10 amp 10 amps 15 amps 15 amps N/A N/A
230 VAC 10 amp 10 amps 10 amps 10 amps 10 amps 15 amps
AC plug
110 VAC yes yes yes yes N/A N/A
230 VAC yes yes yes yes yes yes
Pliers Weight lb/ kg 13 / 6 35 /16 48 / 22 82 / 37 106 / 48* 121 / 55*
Total Weight lb/ kg 22 / 10 70 / 32* 92 / 42* 181 / 82** 225 / 102** 255 / 116**
Max. Belt Width at 90° in/ mm 24 / 300 28 / 720 41.7 / 1060 51 / 1300 66.9 / 1700 82.5 / 2100
Max. Belt Width at 45° in/ mm 6 / 150 15.7 / 400 24.4 / 620 33 / 845 45.7 / 1160 56 / 1420
Belt Thickness: in/ mm
0.06-0.2 /
1.5-5
0.06-0.2 /
1.5-5
0.06-0.2 /
1.5-5
0.06-0.2 /
1.5-5
0.06-0.2 /
1.5-5
0.06-0.2 /
1.5-5
Preheating in minutes 15 15 15 15 15 15
Working Temperature
428 - 518°F 428 - 518°F 428 - 518°F 428 - 518°F 428 - 518°F 428 - 518°F
220 - 250°C 220 - 250°C 220 - 250°C 220 - 250°C 220 - 250°C 220 - 250°C
** This equipment is heavy and must be carried by a forklift.
In the USA, units are supplied with a 110 VAC North American Standard plug. In Europe, units are supplied
with a 230V German standard plug. Users must adapt the plug to the local electrical standards. This must be done
by a certified electrician and in compliance with local electrical codes and standards.
* This equipment is heavy and must be carried by two persons.
5
