52 Operating manual Voltwerk VS 3, 4, 5
7 Maintenance and disassembly
ENGLISH
DO_BA_2008_121LB_3ENG_BVo 22.2.10
1. Take the inverter off the wall.
Result The inverter has been removed.
7.5 Replacing fans
Requirements
| The inverter is isolated (AC and DC).
| The inverter has been removed.
| The inverter is lying on its side.
| 2 fans with assembled cable and plugs have been ordered
from the manufacturer.
Tools requ ired
| Suitable open-ended spanner
Property damage due to incorrect storage.
LED indicators are not flush-mounted and may break under
load.
| Store inverters on their sides or rear sides only.
Inverters with a 3 kW output have no fan.
