VOLTWERK VS 3 - Page 89

26 Operating manual Voltwerk VS 3, 4, 5
4 Transportation and assembly
ENGLISH
DO_BA_2008_121LB_3ENG_BVo 22.2.10
2. Drill four holes in accordance with the drilling template
supplied. Ensure that there is/are:
| Three holes for wall bracket (1)
| One hole for lower fastener (2)
3. Screw the wall bracket on tight.
(1)
(2)
367.40 mm
Property damage due to uneven weight distribution.
| Hold the upper third of the inverter.
