4
SmartBoard
Operation and Functions
30
Position Information Description Note
4 Braking
pressure c,
d
Braking pressure of the TEBS
modulator, axle c, d
5 Braking
pressure e,
f
Braking pressure of the EBS
relay valve.
Only available in
4S /3M systems.
6 Bellows
pressure
Bellow pressure, axle e, f
7 Voltage,
Trailer EBS
System voltage
8 ABS con-
figuration
Number of sensors and solenoid
valves
ODR data
With the ADR version, the internal clock is not active. No time entries are made in
the ODR operating data memory or the diagnostic memory.
Information Description Note
Operating hours Trailer EBS operating hours since
start of production.
Distance driven Distance driven of the Trailer EBS
since fitment.
Trips Number of trips. A trip is defined as a
drive >30 km/h and
>5 km.
Average Axle load
(kg)
Mean axle load value over all
trips.
The combined multi-
axle load is saved.
Average Axle load (%) Mean value of axle loads over all
trips.
Pm_mean Mean control pressure over all
brake actions.
Braking frequency Number of brake actions every
100 kilometres.
Brake actions Number of brake actions. Brake actions when
driving.
Brake 24N Number of brake actions with stop
light activation only.
Brake actions when
driving.
Braking pm Number of brake actions via
pneumatic control line only (CAN
not available).
Brake actions when
driving.
ABS interventions Number of ABS control interven-
tions.
RSS stage 1 Number of RSS test brake ac-
tions.
