WABCO SMARTBOARD - Immobilizer

4
SmartBoard Operation and Functions
18
Notation Description Note
Trip km Kilometre count with ISO
supply connected.
Can be reset in the SmartBoard.
• To reset, select the option "Trip km" and press <OK>.
• Select "Yes" when the message "Reset trip km" appears
and press <OK>.
4.4.2 Immobilizer
The immobilizer is for reducing the risk of theft. The function can be activated or
deactivated by entering a self-defined PIN key via the SmartBoard.
Enabling
A PUK is necessary for each vehicle for enabling the first time. This requires the
document "PUK Access Code 813 000 049 3" with an individual voucher code.
With this voucher code, you can apply for the PUK on the internet under
www.wabco-auto.com/immobilizer.
The job of the PUK is:
• Releasing the immobilizer function in the TEBS E modulator
• Defining / changing the user PIN
• Master key, to also release the vehicle without a PIN
The PUK is reserved only for the end user. Handle the PUK with care and protect it
from access to third-parties and unauthorized persons. Store the PUK in a safe
location. WABCO will not be held responsible for the loss or misuse of the PUK.
– Select the menu <Tools> <Settings> <New PIN>.<with PUK>.
– Please enter the PUK.
– Define a PIN and enter it.
– Re-enter PIN to confirm.
 Upon successful release, a confirmation appears on the display.
Operation
Before deactivating the immobilizer, the park brake (red button of PREV) of the
trailer must be activated.
With Trailer EBS as of generation E2, the park brake of the tow vehicle must be
activated when deactivating the immobilizer and brake pressure must be applied on
the yellow hose coupling.
If the PIN is entered incorrectly 5 times, the PIN entry can only be made again after
a 10 second delay. Another incorrect entry will double the duration of the delay. Af-
ter 20 incorrect entries, the function is locked and must be enabled again using the
PUK.
– Select menu <Immobilizer>.
– Enter the self-defined PIN.
